Introduction
The double roll wood peeling machine makes use of the unique force produced by the rotor with peeling teeth to make the wood section circulate in the bin trough plate repeatedly, and also makes the rotary movement around the axis of the wood section itself, as well as irregular jumping. At this point, the wood segments and teeth, wood segments and wood segments, wood segments and silos are constantly friction, impact, extrusion, bark is quickly separated to achieve the peeling effect.
Application
It is an important equipment in pulping and papermaking, wood processing, chip production and forest cutting in southern forest region. It is widely used in medium density fiberboard factory, paper mill, chip mill, pulp mill, wood storage factory and forest cutting in southern forest region. The machine is suitable for peeling newly cut softwood and part of hardwood, and can also complete the peeling operation of part of frozen wood and dry wood.
Parameter of the Wood peeling machine
Working principle of wood peeling machine:
put logs, branches and other wood into the roller groove, close the feeding baffle, start the machine, and run clockwise. The wood in the roller groove runs with the operation of the machine, so that the peeling knife can peel off the skin on the wood. After 15 minutes, turn off the machine, open the discharge baffle, and then start the machine and run counter clockwise for two minutes. The peeled wood can be automatically sent out from the roller groove. The stripping rate can reach 95%.
Adventages
The double roll wood peeling machine has excellent peeling effect on bending wood, and the maximum bending degree of wood is 8%.
This series of products have eight side cutting edge, high peeling efficiency and long service life; Low cost, hydraulic, photoelectric, mechanical technology comprehensive utilization, optical and mechanical integration, feeding, peeling, peeling, discharging and other whole process automation.
The machine adopts stepless speed change technology and automatically adjusts the feeding speed. It is suitable for various kinds of wood peeling of different tree species, different diameter classes and different bending degrees.
This series of products have good peeling quality and high production efficiency, ranking the domestic advanced technology in technical performance.
Structure and characteristics of double roll wood peeling machine:
The double roll wood peeling machine is the first dry semi continuous and continuous drum type wood peeling machine in China. Its technical performance is at the advanced level in China. The utility model is composed of a cutter shaft, a cylinder body, a feeding baffle plate, a discharging baffle plate and a transmission device. There is a special dry peeling cutter on the inner wall of the drum and a high-speed cutter shaft in the center of the drum. There is no need to use water when peeling, no pollution and public hazard, energy saving and environmental protection. The machine has long service life, low failure rate and simple maintenance. The machine adopts cycloid pin wheel reducer and pin wheel drive, with excellent structure performance, good peeling quality and high productivity. The machine uses advanced dry peeling knife and peeling technology, which can effectively and quickly peel. The peeling diameter can reach 1.2cm. Compared with manual peeling, the efficiency of the machine is increased by 8-60 times, and the peeling cost is only 25% - 30% of manual peeling. The peeling effect of this machine is better than any other type of wood peeling machine.
